Pulsar Thermal Imaging Scope Helion 2 XP50

3150.00 taxe incluse

N° Article : 77402

Rupture de stock

Vous souhaitez être averti lorsque ce produit sera de nouveau en stock ?

Nur auf Bestellung verfügbar

Highly Sensitive Thermal Imaging Sensor

An advanced NETD <40 mK sensor produces precise detail recognition imaging even in adverse weather conditions like rain and fog. Even when thermal contrast is low, small temperature differences are clearly visible with richly contrasted, high-resolution imaging.

Long detection range up to 1800 m

Powerful objective lens in combination with professional grade thermal imaging sensor with NETD 40 mK provides exceptional detection capabilities. A standard 1,8m tall object can be detected at a 1800 m distance in complete darkness.

High Definition Image

Sharp, richly contrasted thermal imaging for enhanced identification of animals, their extremities and even the smallest details, i.e. branches, leaves, grass and terrain.

Variable Digital Zoom

Digital zoom, up to 8x depending on model, provides improved focus and better overall object recognition at significant distances.

Pulsar’s proprietary Image Boost Technology

 is comprised of software algorithms designed to increase imaging clarity and overall image detail. Image Boost results in a sharper, more detailed field of view and enhanced object identifcation capabilities.

Full color AMOLED technology Display

New display delivers crisp, richly contrasted, vividly colored field of view, AMOLED technology ensures flawless, fluid, high-resolution imaging and power saving.

Built-in photo and video recorder

The built-in video recorder is a great asset when it comes to filming or taking photos of once-in-a-lifetime experiences. One press of the REC button captures footage that can be shared easily with colleagues, friends and family. 16 Gb of internal memory provide many hours of recorded video and tons of photos.

.

16 Gb Internal memory

16 Gb of memory offers enough space for recording and taking photos of exciting moments. Recorded files can be later downloaded to PC or smartphone.

Picture-in-Picture

Picture-in-picture displays a magnified image at the top-center 10% of the overall field of view for precise zooming on an object of interest.

IPX7 Waterproof Rated

IPX7 waterproof-rated for protection from rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 3 feet of water for up to 30 minutes.

8 Color palettes

The 8-color palette enhances viewing in varying conditions. While the classic “White Hot” mode is exceptionally versatile, “Hot Black” is often favored for detecting wildlife at night. Red monochrome helps to reduce or prevent bright backlight from exiting the eyepiece. Sepia often improves long-range observation while “Red Hot”, “Rainbow” and “Ultramarine” enhance temperature differences of various object attributes. Violet helps to identify objects faster.



Sepia

Sepia

Hot White

Hot White

Hot Black

Hot Black

Hot Red

Hot Red

Rainbow

Rainbow

Ultramarine

Ultramarine

Red Monochrome

Red Monochrome

Violet

Violet

Sepia

Sepia

Wi-Fi. Integration with IOS and Android devices

Built in Wi-Fi module provides connectivity of thermal imager with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offers a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware update and many other.

More features

Power Supply System B-Pack

Helion includes a progressive autonomous B-Pack power supply consisting of a quick-detach, rechargeable IPS7, 6.4 A-h battery pack designed to deliver over 10 hrs. of operation on maximum mode. Higher-powered IPS14 battery packs, as well as AA battery cases, also are available and provide a perfect off-the-grid power solution.

Stadiametric rangefinder

Helion has a stadiametric rangefinder performed in the shape of rangefinding reticle which enables distance measuring to observed objects with known height (deer - 1,7 m; boar – 0,7 m; hare – 0,3 m) with a sufficient precision.

High image frequency

Due to the high image frequency (50 Hz) it is comfortable to use thermal camera dynamically (during rapid moving of observer or object of observation).

Updatable Software

For initial setup and additional updates, the iOS and Android compatible Stream Vision App ensures the most recent Helion software versions are available.

External Power Supply

Helion makes charging from external sources, such as power banks, fast and easy with a micro-USB jack. The convenience of power-bank charging even enhances the ability to power up the Helion during extremely cold weather while also protecting the source from rapid discharge.

User-friendly interface

The Helion is designed with ease-of-operation in mind. User feedback has resulted in the most friendly interface to date, complete with an easy-to-read, icon-driven, alpha-numeric status bar at the bottom of the display. Internal menu items and options are also displayed on a contrasting gradient substrate so you can keep an eye on settings without losing sight of your objective.

Wide range of operation temperatures

Helion thermal imaging scopes are effective for the use in low temperatures (-25°C) thanks to the frost-resistant AMOLED display employed in the unit (image remains the same as when viewing at positive temperature of the surrounding atmosphere).

Display Off

Display Off

When it is necessary to temporarily stop observation the user can apply Display Off function. It provides the necessary level of camouflage (no light from the eyepiece of the device) between observation sessions as well as the fast restart of observation (when display is turned off, all other systems are working; for normal operation it is enough just to power on the display again).

Main
Sensor
640x480 pix. @ 17 µm (NETD <40 mK)
Objective lens
F50/1.2 (interchangeable)
Magnification, x
2.5 – 20 (x8 zoom)
Field of view (HxV), degrees / m@100m
12.4x9.3 / 21.8x16.3
Detection range, m
1800
Sensor
Type
uncooled
Resolution, pixels
640x480
Pixel pitch, µm
17
NETD, mK
<40
Frame rate, Hz
50
Optics
Objective lens
F50/1.2 (interchangeable)
Magnification, x
2.5 - 20
Magnification in monocular mode / attachment mode, x
-
Field of view (HxV), degrees / m @ 100 m
12.4x9.3 / 21.8x16.3
Eye relief, mm
15
Recommended magnification of the day scope, x
-
Display
Type
AMOLED
Resolution, pixels
640x480
Range Performance
Detection range, m
1800
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014
-
Wavelength, nm
-
Max. measuring range, m
-
Measurement accuracy, m
-
Video Recorder
Video / photo resolution, pixel
640x480
Video / photo format
.avi / .jpg
Built-in memory, Gb
16
Built-in memory capacity
-
Environmental Characteristics
Degree of protection, IP code (IEC60529)
IPХ7 (waterproof)
Operating temperature range, °С
-25 – +50
Power Supply
Output voltage, V
3.0 – 4.2
Battery type
Li-Ion Battery Pack IPS7
Capacity, mAh
6400
Operating time on battery pack (at t=22°C), h *
10
External power supply, V
5 (Micro USB Type B)
Connections and Compatibilities
Mount, type
1/4" socket
Remote control
RCC Remote Control (optional)
Wi-Fi
Frequency, GHz
2.4
Standard
802,11 b/g
Line-of-sight reception range, m
15
Weight & Size
Body material
Glass-nylon composite
Dimensions, mm
234x55x58
Weight, kg
0.5
Trade Data
SKU (Model #)
77402
